Exchanging public keys using a PGP key pair

Tuesday, August 13, 2024 at 11:03 AM | 7 min read

Last modified on Friday, August 16, 2024 at 11:54 PM

#exchanging public keys, #linux, #mutt email client, #asymmetric encryption, #pgp key pair, #gpg, #pgp, #revocation certificate, #security, #series

Exchanging keys

Photo by Pavel Danilyuk Pavel Danilyuk on pexels.com

Table of Contents

This article assumes that you have already created a PGP key pair. If not, please visit my article entitled Making and verifying digital signatures using GPG in Linux.

Exporting the PGP public key

In order to share our public key with others, we can:

  1. Hand it to them.
  2. Email it to them.
  3. Place it online (your website or blog, for example).
  4. Store our key on a keyserver for others to fetch.

For options 1, 2, or 3, we have to export our public key using the --export option. However, we need to transform it into a manageable format. We shouldn't use the raw binary data which can cause all sorts of issues including not being transmittable via email. In order to achieve this, gpg can generate ASCII armored output for us when we use the --armor (or -a) option.

In order to export my public key, I run the following command in Terminal:

gpg --armor --export Maria > maria_publickey.asc

The --export option either exports all keys from all keyrings (default keyring and 1 via option --keyring), or if at least one name is given, those of the given name. The exported keys are written to stdout or to the file given with the option --output. Use together with --armor to email those keys.

The --armor option creates ASCII armored output. The default is to create the binary OpenPGP format. By default, a key is exported in binary format. As mentioned earlier, this is not transmittable via email.

After exporting my key as above, I now have a copy of my public key. And if I ls the current working directory, a new file called maria_publickey.asc appears.

Sending maria_publickey.asc to another local user via email

Next, I can send my maria_publickey.asc file to another user on the local network via email in the following way with Terminal:

mutt -s "Sending Maria public key file" -a maria_publickey.asc -- magdala@maria-VirtualBox
# I'm taken into nano text editor in mutt where at the bottom of the window is the following:
To: magdala@maria-VirtualBox # then I hit return and the following appears:
Subject: Sending Maria public key file # then I hit return and am taken into another window in nano where I type the body of the email where the white cursor is at the top of the window
Hi Magdala,

I am attaching my public key file called maria_publickey.asc for you to use. Thanks!

Best regards,

Maria
# then I hit Control + O key followed by the Return key
# then I hit Control + X key and this takes me to my mutt mailbox where I select the email I want to send by using either the up or down arrow
# after I have selected the email I just wrote and want to send, I press the y key. This results in "mail sent" appearing at the bottom of the window, and then I am taken back to the Terminal command prompt.

I will be writing a separate article about how to set up the mutt email client, write emails to other users locally, and attach files which can then be saved locally by the recipient(s).

Email recipient user magdala imports the maria_publickey.asc

Next, user magdala has to open the email that she has just received.

For user magdala to be able to use my public key, she has to run the following in Terminal:

gpg --import maria_publickey.asc

And the following is then stdout in Terminal:

gpg: key xxxxxxxxxxxxxxxx public key "Maria (GPG key pair for local testing with correct email) <maria#maria-VirtualBox>" imported
gpg: Total number processed: 1
gpg:               imported: 1

I would do the same thing when importing user magdala's public key:

gpg --import magdala_publickey.asc

Once a public key has been imported, we should "sign it".

Signing the imported public key maria_publickey.asc

Now that user magdala has imported my public key, she can run the following command in Terminal:

gpg --edit-key Maria

Which returns the following:

gpg (GnuPG) 2.4.4: Copyright (C) 2024 g10 Code GmbH
This is a free software; you are free to change and redistribute it.
There is NO WARRANTY, to the extent permitted by law.

pub  rsa3072/xxxxxxxxxxxxxxxx
     created: 2024-08-09      expires: never      usage: SC
     trust: unknown           validity: unknown
sub  rsa3072/xxxxxxxxxxxxxxxx
     created; 2024-08-09      expires: never      usage; E
[ unknown ] (1). Maria (GPG key pair for local testing with correct email) <maria2@maria-VirtualBox>

gpg> fpr
# which returns:
pub  rsa3072/xxxxxxxxxxxxxxxx Maria (GPG key pair for local testing with correct email) <maria@maria-VirtualBox>
 Primary key fingerprint: xxxx xxxx xxxx xxxx xxxx xxxx xxxx xxxx xxxx xxxx
# once fingerprint has been verified with the owner, the key is ready for signing
gpg> sign
# and the following is returned:
gpg: no default secret key No secret key
# then to double check that the public key has been signed:
gpg> check

gpg>

The reason that this has happened is because user magdala has not created her PGP key pair. She has to do that now after exiting out of editing key Maria).

When the PGP key pair has been successfully created (check out my article Making and verifying digital signatures using GPG in Linux for a refresher), user magdala can now edit the Maria key pair:

gpg --edit-key Maria
gpg (GnuPG) 2.4.4; Copyright (C) 2024 g10 Code GmbH
This is free software: you are free to change and redistribute it.
There is NO WARRANTY, to the extent permitted by law.

pub  xxxxxxxxxxxxxxxx
     created: 2024-08-09 expires: never      usage: SC
     trust: unknown validity: unknown
sub  rsa3072/xxxxxxxxxxxxxxxx
     created: 2024-0809  expires: never      usage: E
[ unknown ] (1). Maria (GPG key pair for local testing with correct email) <maria@maria-VirtualBox>

gpg> fpr
pub  xxxxxxxxxxxxxxxx 2024-08-09 Maria (GPG key pair for local testing with correct email) <maria@maria-Virtualbox>
  Primary key fingerprint: xxxx xxxx xxxx xxxx xxxx xxxx xxxx xxxx xxxx xxxx

gpg> sign

pub  xxxxxxxxxxxxxxxx
     created: 2024-08-09 expires: never      usage: SC
     trust: unknown      validity: unknown
 Primary key fingerprint: xxxx xxxx xxxx xxxx xxxx xxxx xxxx xxxx xxxx xxxx

     Maria (GPG key pair for local testing witb correct email) <maria@maria-VirtualBox>

Are you sure that you want to sign this key with your key "magdala (This is the second PGP key pair I am creating for local testing because I lost the passphrase for the first one) <magdala@maria-VirtualBox>" (xxxxxxxxxxxxxxxx)

Really sign? (y/N) y # then user prompted for their passphrase

gpg> check

gpg>
Save changes? (y/N) y # then hit Control + D key to exit out of gpg command prompt

Exporting magdala_publickey.asc

To export the magdala public key, first user magdala runs the following command in Terminal:

gpg --armor --export magdala > magdala_publickey.asc

Which results in the creation of the file magdala_publickey.asc.

Before sending her public key to user Maria, user magdala should create a revocation certificate in case if the key pair is lost or compromised.

Creating the revocation certificate for magdala PGP key pair

In order to create a revocation certificate for user magdala's PGP key pair, she has to run the following command in Terminal:

gpg --output ~/revocation.crt --gen-revoke magdala@maria-VirtualBox

sec rsa3072/xxxxxxxxxxxxxxxx  2024-08-14 magdala (This is tjhe second PGP key pair I am creating for local testing because I lost the passphrase for the first one) <magdala@maria-VirtualBox>

Create a revocation certificate for this key? (y/N) y
Pleas select the reason for the revocation:
     0 = No reason specified
     1 = Key has been compromised
     2 = Key is superseded
     3 = Key is no longer used
     Q = Cancel
(Probably you want to select 1 here)
Your decision? 0
Enter an optional description; end it with an empty line:
>
Reason for revocation: No reason specified
(No description given)
Is this okay? (y/N) youASCII armored output forced.
Revocation certificate created

Please move it to a medium which you can hide away; if Mallory gets access ton this certificate he can use it to make your key unusable. It is smart to print this certificate and store it away, just in case your media become unreadable. But have some caution: The print system or your machine might store the data and make ot available to others!
magdala@maria-VirtualBox:~$

User magdala is also prompted for the magdala PGP key pair passphrase during the process as well.

The reason why it is a good idea to immediately create a revocation certificate after generating a PGP key pair is because a revocation certificate CANNOT be created for a PGP key pair AFTER it has been lost or compromised.

Immediately changing permissions for revocation.crt

Once user magdala has generated her revocation certificate, she should immediately change the permissions for her revocation.crt file using the chmod command:

chmod 600 ~/revocation.crt

Then, to confirm her change in permissions, she can run ls -l ~/revocation.crt, and the following is returned:

-rw------ 1 magdala magdala 719 Aug 14 08:13 /home/magdala/revocation.crt
magdala@maria-VirtualBox:~$

Emailing magdala_publickey.asc to user Maria

Now user magdala has to send her public key file to user Maria, so she runs the following in Terminal:

mutt -s "Sending magdala public key file" -a magdala_publickey.asc -- maria@maria-VirtualBox

And the following appears when she hits the Return key:

mutt -s "Sending magdala public key file" -a magdala_publickey.asc -- maria@maria-VirtualBox
# user magdala is taken into nano text editor in mutt where at the bottom of the window is the following:
To: maria@maria-VirtualBox # then she hits return and the following appears:
Subject: Sending magdala public key file # then she hits return and is taken into another window in nano where she types the body of the email where the white cursor is at the top of the window
Hi Maria,

I am attaching my public key file called magdala_publickey.asc for you to use. Thanks!

Best regards,

Magdala
# then she hits Control + O key followed by the Return key
# then she hits Control + X key and this takes her to her mutt mailbox where she selects the email she wants to send by using either the up or down arrow
# after she has selected the email she just wrote and wants to send, she presses the y key. This results in "mail sent" appearing at the bottom of the window, and then she is taken back to the Terminal command prompt.

Now user Maria and user magdala have swapped public keys via the mutt email client in Linux! Next will be to send files to each other, use their public keys to encrypt, and their secret keys to decrypt. This will be the next article in the series after the article on the mutt email client in Linux. Stay tuned for both!

User Maria imports magdala_publickey.asc

Now user Maria has to import magdala_publickey.asc by running the following command in Terminal:

gpg --import magdala_publickey.asc
# which returned:
gpg: key xxxxxxxxxxxxxxxx: public key "magdala (This is the second GPG key pair I am creating for local testing because I lost the passphrase for the first one) <magdala@maria-VirtualBox>" imported
gpg:      Total number processed: 1
gpg:                    imported: 1
maria@maria-VirtualBox:~$

Now both users are ready to share data using each others' public keys!

Asymmetric encryption and decryption series
