The Linux filesystem

At a high level, the Linux filesystem follows the Filesystem Hierarchy Standard (FHS). This standard describes the common layout conventions used by most UNIX and UNIX-like systems. It consists of a single primary or root directory with multiple branching sub-directories.

/ represents the root of the Linux filesystem. It is under this root directory that all other files and directories reside. The Filesystem Hierarchy Standard (FHS) describes the different directories and what files are located in which directories.

If we have Ubuntu or a Ubuntu derivative installed (like Linux Mint for example), we can install a package called tree by running the following command in Terminal:

# to update current packages. updates the list of available packages and their versions, but it does not install or upgrade any packages.
sudo apt update
# actually installs newer versions of the packages you have. After updating the lists, the package manager knows about available updates for the software you have installed. This is why you first want to update.
sudo apt upgrade
# now you are ready to install tree
sudo apt install tree

Now we can run a command like the following:

tree /

The tree command lists contents of directories in a tree-like format in Linux. With no args, it lists the files and sub-directories in the current directory. With directory args (such as / or ~), tree lists all the files and/or directories found in the given directories. When completing the list of all files and directories found, tree returns the total number of files and/or directories listed. It is far too long to share here, but you should definitely run this command to see what is the resulting output.

If we want a short list of files and directories in root (/), for example, we can run something like the following instead:

# run from root directory `/`
tree -L 1 /

This results in the following stdout to Terminal:

/
|___ bin -> usr/bin
|___ boot
|___ cdrom
|___ dev
|___ etc
|___ home
|___ lib -> usr/lib
|___ lib64 -> usr/lib64
|___ lost+found
|___ media
|___ mnt
|___ opt
|___ proc
|___ root
|___ run
|___ sbin -> usr/sbin
|___ srv
|___ swapfile
|___ sys
|___ tmp
|___ usr
|___ var

21 directories. 1 file

What this command essentially is doing is it shows only the first level of the directory tree starting at root (/). The -L option tells tree how many levels down we want to see. Here, we indicate 1 level.

Let's say I run the following command instead, also from / root:

tree -L 2 /

This results in the following stdout to Terminal:

...
479 directories, 369 files

The stdout is too long to share here, but as shown above, it results in 479 directories and 369 files! And so on.

Types of files in Linux

In Linux and Unix systems, everything is considered a file. If it isn't, it's a running process. Basically, files fall under three different categories in Linux:

  • Regular files: these include text files, photos, videos, programs, and executable files.
  • Directories: in Linux, directories are also considered files since they provide storage for other files and sub-directories.
  • Special files: device files that are made up of symbolic links, block files, socket files, and named pipe files.

/bin

The /bin directory, which stands for 'binary' directory, is the root /bin directory where executable files are stored. These /bin directories are storage locations for important commands and programs. If I run the ls /bin command, the following is returned:

'['
7z
7za
7zr
aa-enabled
aa-exec
aa-features-abi
aconnect
acpi_listen
add-apt-repository
addpart
addr2line
add-remove-locales
airscan-discover
alpine
alpinef
alsabat
alsaloop
alsamixer
...
join
...
tar
...
touch
...
whoami
...
zless
zmore
znew
zstd
zstdcat
zstdgrep
zstdless
zstdmt

And if I run ls /bin | wc -l, the following is returned:

1941

That is a lot of commands and programs! One can find out the path to a command by running the which command followed by the command itself. Something like the following:

which crontab
# which returns:
/usr/bin/crontab

The which command locates a command in /bin. Here it locates the path to the crontab command. I can also locate the grep command, for example:

which grep
# which returns:
/usr/bin/grep

On the other hand, a command like cd is a built-in shell command, so running which cd returns nothing. To learn more about built-in shell commands in Ubuntu bash, please visit Ubuntu bash builtins. There is also a great explanation of why cd, for example, cannot be an executable on "ask Ubuntu" in the thread entitled Why wouldn't the which command work for cd? I can't find the executable for cd either!.

/boot

The /boot directory contains all the files needed for starting the system (aka boot process). The /boot directory is mounted directly on the root directory (/) and is called /boot.

When I run ls /boot in my Linux Mint OS Virtual Machine, I get back the following:

config-5.15.0-117-generic      initrd.img.old
config-5.15.0-91-generic       System.map-5.15.0-117-generic
efi                            System.map-5.15.0-91-generic
grub                           vmlinuz
initrd.img                     vmlinuz-5.15.0-117-generic
initrd.img-5.15.0-117-generic  vmlinuz-5.15.0-91-generic
initrd.img-5.15.0-91-generic   vmlinuz.old

Files included in /boot are grub boot loader files [^1], root filesystem files, Linux kernel files (vmlinuz), and other boot configuration files.

grub, or GRand Unified Bootloader, is the boot loader. The current grub is also known as GRUB 2.

GRUB includes its own support for multiple file systems, especially FAT32, ext4, Btrfs or XFS.

initrd, or initial ramdisk, is used for loading a temporary root filesystem into memory, to be used as part of the Linux startup process. initramfs is used as another way of loading a temporary root filesystem into memory and is used as part of the Linux startup process as well. Both methods are commonly used to make preparations before the real root file system can be mounted.

/boot partition

According to archlinux (a lightweight Linux distribution),

The boot loader must be able to access the /boot partition. In other words, the boot loader must have support for everything starting from the block devices, stacked block devices (LVM, RAID, dm-crypt, LUKS, etc) and ending with the file system on which the kernel(s) and initramfs image(s) reside...File systems can get new features not yet supported by boot loaders (e.g. archlinux/packaging/packages/grub#7, FS#79857, FS#59047, FS#58137, FS#51879, FS#46856, FS#38750, FS#21733 and fscrypt encrypted directories), making them unsuitable for a /boot partition unless disabling incompatible features. This can be typically avoided by using FAT32 since it is supported by practically everything and it will not be getting any new features.

In addition, FAT32 works with all versions of Mac, Windows, Linux machines, and gaming devices.

That being said and shown, it is important to note that we should not touch anything in /boot, otherwise it might break our system and we would not be able to run our Linux OS. However, as long as we are not running as root, we would not be able to access /boot anyway.

/cdrom

When I ran ls -l /cdrom, the following was returned:

total 0

Apparently, it is an empty directory in Linux Mint. I could not find anything specifically about this directory in Linux Mint, but I did find the following about /cdrom in Linux on askUbuntu:

While /mnt/ and /media/ are common places to mount devices, the device location can be just about anywhere. /cdrom/ was probably chosen for either brevity or legacy support.

But of course this was from 2010, so who knows what its function is today on Linux Mint, especially since it is an empty directory. I subsequently found another thread entitled cdrom folder empty on the Linux Mint forum, and a user there stated the following in response to another user's question as to why the /cdrom directory was empty:

What makes you think that the folders should go anywhere other than where they already are?... and what makes you think that you should open them?

My system has been working perfectly for years... my cdrom folder is empty and my dev folder has almost 200 files - all of which contain 0 bytes! What I am trying to say here is that I don't think there is anything wrong with your cdrom folder or your dev folder...

I would suggest starting another thread or retitling this thread to something like "I can't use my DVD drive". Then edit your first post to include more information... the whole error message including what happens if you press S or M; what Mint version and DE your are using; does the DVD icon appear in you Computer view?; etc...

Don't worry about this one, especially if you are a Linux Mint user like myself. It's an empty directory, and it seems to be meant to be empty. Just move on!

/dev

/dev contains device files. When we connect a device to our machine, the device usually needs a device driver to function properly. We can interact with device drivers through device files or device nodes [^1]. These are special files that look like regular files. Since these device files are just like regular files, we can use programs such as ls, cat, etc., to interact with them.

The system creates /dev files during installation, and they must be available during the boot process. Device files are abstractions of standard devices that applications interact with via I/O system calls [^2].

Most of the files listed (ls -l /dev) are either block or character devices. We can tell which is which by the first character in the file's permissions. For example, if the first character in the file's permissions is a c, that means it is a character file.

block devices

# example of a black file in /dev
brw-rw----  1 root disk     7,  0 Jul 28 09:33 loop0

The above is a block device file as indicated by the b in column 1, the file permissions.

Column 2 is the number of links.

Column 3 is the owner (root).

Column 4 is the group (disk).

Column 5 is the major device number (7).

Column 6 is the minor device number (0).

Column 7 is the timestamp (Jul 28 09:33).

Column 8 is the device name (loop0).

/dev/loop* are loop devices making plain files accessible as block devices. They are typically used for mounting disk images. Drivers access data from block devices via a cache, and drivers communicate with block devices by sending blocks of data. Examples of block devices are hard drives, filesystems, or USBs (Universal Serial Bus).

character devices

Character device files in Linux are special files that allow direct communication between user programs and hardware devices. They are part of the Linux filesystem and play a crucial role in Linux system administration.

Character device files, also known as character special files, provide access to devices that transfer data character by character. These devices typically include terminals, serial ports, and input/output (I/O) devices such as keyboards and mice. Unlike regular files, character device files do not store data but instead act as a conduit for data transfer between user programs and the underlying hardware.

Device major and minor numbers

Devices are characterized using two numbers. Major device number and minor device number. The major device number represents the device driver that is used, and the minor device number tells the kernel which unique device it is in the driver class. A 0 as shown in the example below, indicates that it's the first device.

brw-rw----  1 root    disk      8,   0 Jul 28 09:33 sda # first hard disk

Each driver is assigned a unique major number, and all device files with the same major number are controlled by the same driver.

The minor number is used by the driver to distinguish between the different hardwares it controls. For example, although three devices may be handled by the same driver, they have unique minor numbers because the driver sees them as being different pieces of hardware.

Device names

The most common device names that appear in /dev are SCSI devices, Pseudo devices, and PATA devices.

SCSI devices use the SCSI protocol. SCSI stands for Small Computer System Interface, and it is used to allow communications between disks, printers, scanners, and other peripherals on the system. SCSI devices are not used on modern systems, but in Linux, SCSI disks correspond with hard disk drives in /dev. They are identified by the sd prefix (SCSI disk). In my Linux Mint OS, I have the following sds:

brw-rw----  1 root    disk      8,   0 Jul 28 09:33 sda # first hard disk
brw-rw----  1 root    disk      8,   1 Jul 28 09:33 sda1 # first partition on the first hard disk
brw-rw----  1 root    disk      8,   2 Jul 28 09:33 sda2 # second partition on the first hard disk
brw-rw----  1 root    disk      8,   3 Jul 28 09:33 sda3 # third partition on the first hard disk

And if I had /dev/sdb, it would represent the second hard disk.

Pseudo devices are not really connected to the system. And most pseudo devices are character devices such as the following:

# accepts and discards all input, produces no output
crw-rw-rw-  1 root root   1, 3 Jul 28 09:33 null
# produces random numbers
crw-rw-rw-  1 root root   1, 8 Jul 28 09:33 random
# accepts and discards all input, produces a continuous stream of NULL (zero value) bytes
crw-rw-rw-  1 root root   1, 4 Jul 28  09:33  zero

With PATA devices, which appear in older systems, we may see hard drives that are represented by the hd prefix:

/dev/hda # First hard disk
/dev/hdd2 # Second partition on 4th hard disk

Symbolic links in /dev are there for a number of reasons.

Examples of symbolic links are /dev/stdin, /dev/stdout, and /dev/stderr:

lrwxrwxrwx  1 root    root          15 Jul 28 09:33 stderr -> /proc/self/fd/2
lrwxrwxrwx  1 root    root          15 Jul 28 09:33 stdin -> /proc/self/fd/0
lrwxrwxrwx  1 root    root          15 Jul 28 09:33 stdout -> /proc/self/fd/1

A symbolic link, aka symlink, to another file is indicated by an l at the beginning of the file permission, as above. A symbolic link is a file in Linux that points to other files or directories and represents their absolute or relative path.

/dev/stdin points to /proc/self/fd/0, for example, because /proc/self sits on the /proc filesystem. When a process reads /proc/self, it gets information about itself using its process id. The /proc/self directory is a symbolic link as well:

lrwx------ 1 maria maria 64 Jul 29 06:53 /proc/self/fd/0 -> /dev/pts/0

When I run ls -l /dev/cdrom, the following is returned in Terminal:

lrwxrwxrwx  root root 3 Jul 28 09:33 /dev/cdrom -> sr0

And what does /dev/cdrom -> sr0 mean? sr0 is a device on the scsi controller [^3] (hypervisor). For those of us that use Linux in A VM (virtual machine) like VirtualBox, for instance, it is the "cdrom" that we use to upload our Linux ".iso" image [^4] file into VirtualBox to install our Linux distribution in the VM.

There are 203 files and folders in my Linux Mint /dev directory. Among them (and in Linux in general)are /dev/null, which is a virtual device that discards any output of a script or command that we redirect to it. I discuss it and provide examples in my article entitled stdin stdout and stderr in Linux and Unix (macOS).

There is more to /dev than covered here. To learn more, you can visit devices on linuxjourney.com.

/etc

/etc originally stood for "et cetera" because it was where anything that was difficult to find a place for was placed. Now "etc" refers to everything that needs to be configured. It contains most if not all system-wide configuration files. Some examples of configuration files in /etc:

# The user database, with fields giving the username, real name, home directory, and other information about each user. The format is documented in the passwd manual page.
-rw-r--r--  1 root root 3035  Jul 26 00:08  /etc/passwd
# /etc/shadow is an encrypted file the holds user passwords.
4 -rw--r------ 1 root shadow 1584Jul 26 00:08 /etc/shadow
# Files executed at login or startup time by the Bourne, BASH , or C shells. These allow the system administrator to set global defaults for all users. Users can also create individual copies of these in their home directory to personalize their environment. See the manual pages for the respective shells.
-rw-r--r--   1 root root  582 Oct 15 2021 /etc/profile
-rw-r--r--   1 root root 2319 Jan  6 2022 /etc/hash.bashrc
# Lists trusted shells. The chsh command allows users to change their login shell only to shells listed in this file. ftpd, is the server process that provides FTP services for a machine, will check that the user's shell is listed in /etc/shells and will not let people log in unless the shell is listed there.
-rw-r--r--   1 root root  128 Jan  9 2024 /etc/shells

/home

/home is where users' personal directories reside. In my case, there is one directory under /home: /home/maria. I have created another user on the system called magdala, and her /home directory contains /home/magdala.

/lib

/lib is a symbolic link for usr/lib:

lrwxrwxrwx  1 root root 7 Jul 12 20:38 /lib -> usr/lib

There are 137 files and folders in /usr/lib:

ls -l /usr/lib | wc -l
# which returns:
137

/usr/ib includes libraries for programming and packages. On some systems, it may also include internal binaries that are not intended to be executed directly by users or shell scripts.

Applications may use a single sub-directory under /usr/lib. If an application uses a sub-directory, all architecture-dependent data exclusively used by the application must be placed within that sub-directory. Some examples are:

drwxr-xr-x  5 root root 4096 Jul 25 13:14 libreoffice
drwxr-xr-x  3 root root 4096 Jan  9 2024  linux
drwxr-xr-x 13 root root 4096 Jan  9 2024  linuxmint

/lib64

/lib64 is a symbolic link to /usr/lib64:

lrwxrwxrwx  1 root root 9 Jul 12 20:38 /lib64 -> usr/lib64

/usr/lib64 is for 64-bit libraries.

According to eitca.org,

/lib64 also includes libraries for programming and packages. /lib64 (and /lib) directories are the default locations where shared libraries are stored in Linux systems. The "lib" directory is present on 32-bit systems, while the "lib64" directory is used on 64-bit systems. These directories contain numerous shared libraries that are essential for the functioning of the Linux kernel, system utilities, and third-party applications. From a Linux system administration perspective, the "lib" and "lib64" directories are critical for managing shared libraries. Administrators need to ensure that these directories are properly maintained, as any issues with shared libraries can lead to application crashes, security vulnerabilities, or system instability.

/lost+found

My /lost+found directory is empty, and oftentimes they are. However, they are system created directories and should not be touched. They may be used by the system, specifically the fsck command.

According to man fsck,

The fsck command checks and repairs a Linux filesystem. fsck is used to check and optionally repair one or more Linux filesystems. Filesystem can be a device name such as /dev/hdc1 or /dev/sdb2, a mount point (i.e. /usr or /home), or a filesystem label or UUID specifier (i.e., UUID=8868abf6-88c5-4a83-98b8-bfc24057f7bd, or LABL=root). Normally, the fsck program will try to handle filesystems on different physical disk drives in parallel to reduce the total amount of time needed to check all of them.

/media

On my Linux Mint OS in VirtualBox, the /media directory contains the following:

ls -lh /media
# which returns:
total 4.0K
drwxr-x---+ 3 root root 4.0K Jul 28 09:33 maria
# to find out what is in the maria directory:
ls -lh /media/maria
# which returns:
total 3.0K
dr-xr-xr-x 5 maria maria 2.6K May 22 05:22 VBox_GAs_7.0.18

The above is my Guest Additions, which is needed in order to select bidirectional Drag and Drop and Shared Clipboard. By default, they are both disabled. In order to change them to "Bidirectional", we have to go to the General tab in our Linux Mint Settings and then select the "Advanced" tab. If we want to be able to copy from Linux Mint in VirtualBox onto our native OS (like Windows 11 for example), we need to properly mount and install VBox_GAs_7.0.18 ".iso" in VirtualBox.

/mnt

/mnt is a legacy directory. It is where we used to manually mount storage devices or partitions. It is not used much these days.

According to the Linux Mint forum, one can delete /mnt if one wants to as long as the directory is empty. For example, mine is empty, but I'm not going to touch it anyway.

/opt

The /opt directory is used for optional add-on software packages, or anything that is not part of the base system. For example, in my /opt directory, I have the following:

ls -lh /opt
# returns:
total 4.0K
drwxr-xr-x 8 root root 4.0K Jul 26 00:08 VBoxGuestAdditions-7.0.18

Only some distributions use /opt. Others use /usr/local.

/proc

/proc, aka the proc filsesystem, like /dev, is a virtual directory. It contains special files that provide us with information about our computer such as the CPU and the kernel our Linux OS is running. The files and directories are generated when our computer starts, or on the fly, as our system is running and things change. /proc is regarded as the information and control center of the Linux kernel.

The proc filesystem is removed once the system is powered off. It is mounted at /proc mount point during the booting process.

/root

The /root directory, as opposed to /, contains the following in my Linux Mint OS:

ls -lah /root
# which returns:
total 28K
drwx------  4 root root 4.0K Jul 25 23:51 .
drwxr-xr-x 19 root root 4.0K Jul 12 20:46 ..
-rw-r--r--  1 root root 3.1K Oct 15  2021 .bashrc
drwx------  2 root root 4.0K Jan  9  2024 .cache
-rw-r--r--  1 root root  161 Jul  9  2019 .profile
drwx------  3 root root 4.0K Jul 25 23:53 .synaptic
-rw-------  1 root root 1.3K Jul 21 19:37 .viminfo

The root (/) directory, mentioned previously, represents the root of the Linux filesystem. It is under this root directory that all other files and directories reside. On the other hand, the /root directory is the home directory for the root user. The /root contains the files we created when we were root user and also the hidden configuration files for some applications or packages we installed. For example, I installed the vim text editor, and now /root contains a file called .viminfo.

The .viminfo file is used to store:

- The command line history.
- The search string history.
- The input-line history.
- Contents of non-empty registers.
- Marks for several files.
- File marks, pointing to locations in files.
- Last search/substitute pattern (for 'n' and '&').
- The buffer list.
- Global variables.

/run

/run is a temporary filesystem that contains volatile runtime data that shows what the system has since it was booted. Files under the /run directory must be deleted (removed or truncated for convenience) at the start of the boot process.

When I run ls /run the following is returned in Terminal:

acpid.pid             cups             lvm              speech-dispatcher
acpid.socket          dbus             mount            sudo
agetty.reload         dmeventd-client  network          systemd
alsa                  dmeventd-server  NetworkManager   tmpfiles.d
avahi-daemon          fsck             openvpn          udev
blkid                 initctl          openvpn-client   udisks2
casper-md5check.json  initramfs        openvpn-server   user
console-setup         irqbalance       plymouth         utmp
credentials           lightdm          pppconfig        uuidd
crond.pid             lightdm.pid      samba            VBoxDRMClient
crond.reboot          lock             sendsigs.omit.d  zed.pid
cryptsetup            log              shm              zed.state

/sbin

/sbin is similar to /bin, but it contains applications that only the superuser needs. We can use these applications with the sudo command that provides us with superuser powers on many distributions. /sbin typically contains tools that can install things, delete things and format things. Some of these instructions are lethal if we don't use them properly, so we should handle them very carefully.

/usr/sbin

/usr/sbin contains executable programs, mostly used by system administrators, usually the superuser. These programs require root permissions.

/srv

/srv contains data for servers. My /srv directory is empty, but then I have not yet tried to set up a server. I have, however, installed node.js and will be testing out creating simple servers with it re-building projects I have created on macOS to quickly see what the similarities are and the differences in the build process.

/swapfile

/swapfile is a swap space partition which is either configured by the user or system installer. Such a partition is dedicated to swapping. It may be slightly faster than using a swapfile, which is just a regular file inside our directory tree (and likely stored in the root folder) if it is on the same disk as the operating system. The size of my swapfile partition is slightly bigger than 2GB, which is pretty large.

When I run ls -lah /swapfile, the following is returned:

-rw------- 1 root 2.06 Jul 12 Jul 12 20:38 /swapfile

/sys

/sys is another virtual directory like /proc and /dev and also contains information from devices connected to our computer. In some cases we can also manipulate those devices. But to do that we have to become superuser. The reason for that is, as with so many other virtual directories, messing with the contents and files in /sys can be dangerous and we can destroy our system. Writing to these files may or may not write to the actual device, depending on the setting we're changing. It isn't only for managing devices, but it is mostly used for that.

When I run ls /sys, the following is returned:

block   class   devices   fs          kernel  power
bus     dev     firmware  hypervisor  module

/tmp

The /tmp directory contains temporary files, usually placed there by applications that we are running. The files and directories often (not always) contain data that an application doesn’t need right now, but may need later on.

We can also use /tmp to store our own temporary files. /tmp is one of the few directories under / that we can actually interact with withouttheneedto becomesuperuser`.

When I run ls -lah /tmp, the following is returned:

total 68K
drwxrwxrwt 16 root  root  4.0K Jul 29 12:29 .
drwxr-xr-x 19 root  root  4.0K Jul 12 20:46 ..
-rw-------  1 maria maria    0 Jul 29 09:27 config-err-rXGF3b
drwxrwxrwt  2 root  root  4.0K Jul 29 09:27 .font-unix
drwxrwxrwt  2 root  root  4.0K Jul 29 09:27 .ICE-unix
srw-rw-rw-  1 root  root     0 Jul 29 09:27 .iprt-localipc-DRMIpcServer
drwxrwxrwx  2 maria maria 4.0K Jul 29 09:27 mintUpdate
drwx------  3 root  root  4.0K Jul 29 09:27 systemd-private-1c36d4307da64425a7f807f98ab15818-colord.service-q0oBPs
drwx------  3 root  root  4.0K Jul 29 09:27 systemd-private-1c36d4307da64425a7f807f98ab15818-ModemManager.service-9iFgLL
drwx------  3 root  root  4.0K Jul 29 09:27 systemd-private-1c36d4307da64425a7f807f98ab15818-switcheroo-control.service-mePlYv
drwx------  3 root  root  4.0K Jul 29 12:29 systemd-private-1c36d4307da64425a7f807f98ab15818-systemd-logind.service-vApiMX
drwx------  3 root  root  4.0K Jul 29 10:55 systemd-private-1c36d4307da64425a7f807f98ab15818-systemd-resolved.service-y4F3hZ
drwx------  3 root  root  4.0K Jul 29 12:29 systemd-private-1c36d4307da64425a7f807f98ab15818-systemd-timesyncd.service-O1h3qX
drwx------  3 root  root  4.0K Jul 29 09:27 systemd-private-1c36d4307da64425a7f807f98ab15818-upower.service-TY3ZQQ
drwxrwxrwt  2 root  root  4.0K Jul 29 09:27 .Test-unix
drwxrwxrwt  2 root  root  4.0K Jul 29 09:27 VMwareDnD
-r--r--r--  1 root  root    11 Jul 29 09:27 .X0-lock
drwxrwxrwt  2 root  root  4.0K Jul 29 09:27 .X11-unix
drwxrwxrwt  2 root  root  4.0K Jul 29 09:27 .XIM-unix

/usr

The /usr directory is one of the most important directories because it contains all user binaries, their documentation, libraries, header files, etc. User programs like telnet, ftp, etc. also reside here. Originally, /usr was where the home directories of the users were placed (/usr/someone was then the directory now known as /home/someone). /usr is where user programs and data (as opposed to 'system' programs and data) are. The name hasn't changed, but it's meaning has narrowed and lengthened from "everything user related" to "user usable programs and data".

When I run ls -lah /usr, the following is returned:

total 136K
drwxr-xr-x  12 root root 4.0K Jan  9  2024 .
drwxr-xr-x  19 root root 4.0K Jul 12 20:46 ..
drwxr-xr-x   2 root root  68K Jul 27 11:22 bin
drwxr-xr-x   2 root root 4.0K Jan  9  2024 games
drwxr-xr-x  41 root root 4.0K Jul 26 00:04 include
drwxr-xr-x 128 root root 4.0K Jul 27 07:32 lib
drwxr-xr-x   2 root root 4.0K Jul 25 13:13 lib64
drwxr-xr-x  20 root root 4.0K Jul 25 13:14 libexec
drwxr-xr-x  10 root root 4.0K Jan  9  2024 local
drwxr-xr-x   2 root root  20K Jul 26 00:08 sbin
drwxr-xr-x 322 root root  12K Jul 27 07:32 share
drwxr-xr-x   6 root root 4.0K Jul 26 00:06 src

/var

The /var directory originally got its name because its contents was considered variable, because it changed frequently. Today the name is a bit misleading, because there are many other directories that also contain data that changes frequently, especially virtual directories such as /proc, /sys, and /dev, for example.

/var contains things like logs in the /var/log sub-directories. Logs are files that register events that happen on the system. If something fails in the kernel, it will be logged in a file in /var/log, If someone tries to break into our computer from outside, our firewall will also log the attempt in /var. It also contains spools for tasks. These “tasks” can be the jobs we send to a shared printer when the task is queued, because another user is printing a long document, or mail that is queued to be delivered to users on the system.

When I run ls -lah /var, the following is returned:

total 44K
drwxr-xr-x 11 root root   4.0K Jan  9  2024 .
drwxr-xr-x 19 root root   4.0K Jul 12 20:46 ..
drwxr-xr-x  2 root root   4.0K Jul 28 23:20 backups
drwxr-xr-x 21 root root   4.0K Jul 26 00:04 cache
drwxr-xr-x 74 root root   4.0K Jul 27 07:32 lib
drwxrwsr-x  2 root staff  4.0K Apr 18  2022 local
lrwxrwxrwx  1 root root      9 Jul 12 20:46 lock -> /run/lock
drwxrwxr-x 12 root syslog 4.0K Jul 229 06:30 mail
drwxr-xr-x  2 root root   4.0K Ja9 09:27 log
drwxrwsr-x  2 root mail   4.0K Jul n  9  2024 opt
lrwxrwxrwx  1 root root      4 Jul 12 20:46 run -> /run
drwxr-xr-x  8 root root   4.0K Jul 25 13:24 spool
drwxrwxrwt  9 root root   4.0K Jul 29 12:57 tmp

Footnotes

[^1]: Device nodes, aka devices, are the files that the kernel, applications, and even command-line tools use when they need to access the hardware.

[^2]: I/O (input/output) system calls are calls that a program makes to the system kernel to provide services the program does not have direct access to. Examples are providing access to stdin devices such as keyboards and stdout devices such as a terminal window/screen.

[^3]: Storage controllers connect disk drives to a computer. In the context of virtual machines, they are used to access virtual disks, CD/DVD-ROM, and SCSI devices. An scsi controller is a type of storage controller.

[^4]: An ISO image (.iso) a CD-ROM image saved in ISO-9660 format. ISO images are mainly used as source files from which to create CDs. As an example, most distributions of Linux release ISO images of the installation CDs. These images are usually freely available online. -- LinuxLookup
